Ceramic rod

Location：Home > Ceramic Product > Ceramic structure parts > Ceramic rod >

Overview
Features
Sizes and types
Application
Machining

As a ceramic rod factory
We produce and sales multi types ceramic rods,also offer customization service

We can manufacture and sales the available sizes of ceramic rods range from 0.393” to 21.654” (10mm – 550mm) length.
The ceramic materials we use:95%--99.99%Alumina (Al2O3)/ Zirconia(ZrO2:TTZ,YTZP, ZDY) /Si3N4 /SiC...
Delivery times：2 -25 days(depends on the quantity) Factory price and shipment within 24 hours In stocks
Features：Heat resistance / Wear resistance / High purity / Refractory / High Corrosion / Good Insulation...
The type:Shaft,Plunger Rod,Piston Rod,Cylinder Rod,Insulating Rod,Tube Bar,sharpening rod,Stick rod, Pin...

Ceramic rod features:

1. Refractory, High Temperature Resistance, Maximum Used Temperature: 1800 ºC (3272ºF)...
2. Hardness Strength, Wear Resistance Up To Mohz 9.0 ; HRA 80-90...
3. High Voltage, Good Insulation Performance ,Electrical Resistivity Up To 10∧14 Ohm.Cm...
4. High Polished Surface Up To Rz0.8(Ra0.1) ...
5. Superior Mechanical Strength, MAX 10 MPa.m1/2 Fracture toughness,
6. Pressure Resistance, Max 2300MPa compressive strength...
7. Anti-High Corrosion Resistance, Such As Acid Alkali Resistance...
8. Long Service Life...
9. Other excellent property

>More ceramics rod property
>More ceramic rod process

We manufacture and sell high-quality, high-precision ceramic rods. Our ceramic rods are multi-size, multi-type and have a wide range of applications.

Dimensions:0.393” to 21.654” (10mm – 550mm) length;Diameter as small as 0.2mm(can be customizations)

The type of ceramic rod
Cylindrical, Square, Screw Threadand, Porous...

Shaft,Plunger Rod,Piston Rod,Cylinder Rod,Insulating Rod,Heat Conducting Bar,sharpening rod,honing rod...

Applications of ceramic rod/bar/sticks:

automotive, aviation, space travel	laboratory technology
electrical and thermal insulation	laser technology
electronics and sensors	mechanical and chemical process engineering
energy technology, power generation	metal industry
environmental technology	optics
fluid technology	semiconductor processing equipment
friction-reduction, wear- and corrosion -protection	surface treatment
high temperature applications	vacuum technology

Ceramic rods have a wide range of applications.Ceramic rods of different sizes are required in every industry.Please contact us for related ceramic rods.

Ceramic rod machining technical parameters:

Dimensional accuracy：Up to 0.001mm

Smoothness：Highest possible mirror

Concentricity：Up to 0.003mm

The inner hole tolerance： 0.005mm

Straight flute：The narrowest 0.1x100mm

The thickness of the size：Minimum to 0.02mm

The screw thread：Minimum thread M2

The smallest aperture：The minimum 0.07mm

We provide customized ceramic rods of different specifications, high quality, factory price, fast delivery

Lead time: 2--20 working days for the mass with free sample of mass ; MOQ : 1 qty
