Advance Ceramic Tubes

Sales and Custom Multi Types and Sizes Ceramic Tubes by Ceramic Manufacturer. delivery time: 1-2 days within in stocks.

Outside Dia:

Inside Dia:

Quantity:

Materials:

Length:

Hole types:

Other details:
Contactways:
Customization & Machining Service:

As a ceramic tube manufacturer,us offer a wide of the ceramic tube,and customized & machinables. We can machining ceramic tubes, such as surface polishing, internal and external pipe wall threads, metal parts bonded, different shapes etc by customers requirement. Get a Quote On Your Customized Now!! or up a files by (email:admin@cerampart.com).


As a the manufacturer of ceramic tubes, us offer a wide the type or sizes of the ceramic tube for industry machinable and parts applications.our ceramic tubes are made of Zirconia, Alumina, Silicon and other advanced ceramics. In stocks and offer customization.
Type of ceramic tubes us manufacturer (including but not only belows)
Thermocouple protection tube
Insulated tube
Inner core
Furnace tube
Heating tube
Radiant tubes
Pump body tube
Inner liner tube
Round tube
Bushing tube
Roller tube
Single / mutli holes tube
Dimension :
Inside Diameter as small as 0.3 mm
Longth as long as 500mm, as short as 0.5mm
Inside Diameter tolerance as 0.002mm
Outside Diameter tolerance as fine as 0.001mm
Minimum thickness of tube wall:0.2mm
The length and special sizes can be customized
ceramic tube alumina tubes
Ceramic materials:
1. Alumina ceramic(Al2O3):
95%;96%;97%;98%;99%;99.5%:99.7%;99.9%
2. Zirconia ceramic(Zro2):
TTZ: Magnesia Partially Stabilized Zirconia (Zro2)
YTZP: Yttria Partially Stabilized Zirconia (Zro2)
ZDY: Yttria Fully Stabilized Zirconia (Zro2)
3. Silicon Carbide
4. Silicon Nitride
5. And others


Our ceramic tubes and rods are available in a wide variety of sizes, shapes, and configurations:
single bore, double bore, four bore, dee tubing, oval shapes, custom shapes



Specification:
1. Refractory, High Temperature Resistance, Maximum Used Temperature: 1800 ºC (3272ºF)...
2. Hardness Strength, Wear Resistance Up To Mohz 9.0 Levels...
3. High Voltage, Good Insulation Performance ,Electrical Resistivity Up To 10∧14 Ohm.Cm...
4. High Polished Surface Up To Rz0.8(Ra0.1) ...
5. Superior Mechanical Strength, Max 10 MPa.m1/2 Fracture toughness
6. Pressure Resistance, Max 2300MPa compressive strength...
7. Anti-High Corrosion Resistance, Such As Acid  Alkali Resistance...
8. Long Service Life...
9. Other excellent property

Other ceramic tubes products

ceramic tube insulators ceramic tube socket ceramic tube core ceramic tube cylinders
ceramic tube heater ceramic tubing fittings ceramic tube ferrule others

User industries:
Automotive, aviation, space travel
Electrical and thermal insulation
Electronics and sensors
Energy technology, power generation
Environmental technology
Fluid technology; Surface treatment
Friction-reduction, wear- and corrosion -protection
High temperature applications
Laboratory technology; Laser technology
Mechanical and chemical process engineering
Metal industry;Optics
Semiconductor processing equipment
Vacuum technology;Other industries


Part of ceramic tube in stocks:
Length Range
Outside Diameter
Inside Diameter
102-174 mm
0.79 mm
0.13 mm
175-327 mm
0.79 mm
0.13 mm
328-479 mm
0.79 mm
0.13 mm
102-174 mm
4.75 mm
0.79 mm
102-174 mm
1.19 mm
0.25 mm
175-327 mm
1.19 mm
0.25 mm
328-479 mm
1.19 mm
0.25 mm
480-500 mm
1.19 mm
0.25 mm
175-327 mm
3.96 mm
0.79 mm
102-174 mm
1.57 mm
0.41 mm
175-327 mm
1.57 mm
0.41 mm
328-479 mm
1.57 mm
0.41 mm

Ceramic materials(include but not limited belows)
· 95%--99.99% Alumina (Al2O3)   · Silicon Carbide   · Silicon Nitride  · TTZ: Magnesia partially stabilized Zirconia (ZrO2)
· YTZP: Yttria partially stabilized Zirconia (ZrO2)   · ZDY: Yttria fully stabilized Zirconia (ZrO2)...



Al 23
ZrO2/Y2O3 ZrO2/MgO MgO SiC Si3N4 Reaction sintered Si3N4 Hot pressed ALN
Physical properties
Density (g/cm3) 3,9 5,9 5,75 3,58 3,2 3,27 3,29 3,26
Molecular weight (g/mole) 102 - - 40,4 40,1 140 140 41
Maximum service temperature air (°C) 1700- 1800 1500 1000 2200 1500 1200- 1500 1100- 1600 1000- 1800
Mechanical properties
Hardness (Mohs) 9 - - 5,5 9 - - 7
Modulus of elasticity (GPa) 300-400 200 200 250-300 420 170-220 280-310 318
Poisson's ratio 0,25 - - 0,18 0,14 0,25-0,26 0,27 0,25
Fracture toughness (MPa.m1/2) 2-3 7-13 6-10 - 2,5-3,5 3,5-5 6,1 4,5
Electrical properties
Dielectric constant 9-10 - - 9-10 - 10 10 9,2
Electrical resistivity at 20°C (Ohm.cm) >10 14 10 13-10 14 >10 10 - 10 2-10 6 >10 7 10 12- 10 15 >10 14
Dielectric strength (kV/mm) 10-20 9 2-10 - - - - 15
Thermal properties
Specific heat (J/K/kg) 900 400-500 420 870-880 750 690 680-800 800
Thermal conductivity (W/m/K) at 20°C 26-35 2,2-3,2 1,5-2,5 40-50 63-155 9-30 15-43 180
Coefficient of thermal expansion ( 10-6) from 20 to 1000°C 8-9 10-11 5-16 10-13 4-5 3 3,3 4,4-5,3
Melting point (°C) 2050 2590 - 2800 2500 1900 1900 2200



Customization & Machining Service:
As a ceramic parts manufacturer,us offer a wide of the ceramic specification,and customized&machinables. Get a Quote On Your Customized Now!!  or up a files by EMAIL.

Our Custom Capabilities:
1.High Purity Martoxid Powder
2.OEM Support, More Than 10 Technicians With 5-Year R&D Experience
3.35000 ㎡workshop, annual output could reach hundred million pieces.
4.All crafts are inspected strictly based on drawings,checked each month.
5.Best Service And Quick Delivery Via Fedex,DHL,UPS,TNT Etc.



Technical reference of manufacture
Dimensional accuracy Up to 0.001mm
Concentricity Up to 0.003mm
Parallelism Up to 0.002mm
The inner hole tolerance The minimum  0.005mm
Straight flute The narrowest 0.1x100mm
The thickness of the size Minimum to 0.02mm
The screw thread Minimum internal thread M2
Cylindricity Up to 0.004mm
The linear tolerance Up to 0.001mm
The smallest aperture The minimum 0.07mm
Precision process CNC maching,grinding,lapping
Surface finish Glazed,polishing or metallized

FAQ
1. Monthly Capacity: 50,000-60,000 pcs;
2. Material: OEM or as per your suggestion;
3. Lead time: about 7-20 days, pls confirm the quantities required;
4. Incoterm: FOB, CFR, CIF;
5. Delivery Cost: It is determinated by the destination port;
6. Payment Term: PayPal; T/T; L/C.
7. Shipment: by sea, by air, by courier, by post, etc.

alumina tubes
