As a Professional Advanced Technology Ceramic Manufacturers, Us Support To Customize Different Specifications Of Ceramic Components
Brief Introduction:
Ceramic rod has the characteristics of high temperature resistance, cold resistance, wear resistance, corrosion resistance, electromagnetic insulation, non-oil self-lubrication, high speed and so on.It is widely used in aviation, aerospace, navigation, petroleum, chemical industry, automobile, electronic equipment, metallurgy, electric power, textile, pump, medical equipment, scientific research, national defense and military and other fields. It is a high-tech product for the application of new materials.
we can produce ceramic rods of different sizes, not limited to the following table.
The sizes of some ceramic rods are as follows :
|
 The shapes of the ceramic rods we produce are as follows: round, hexagon, square, semicircle, polygon, hole, etc. Can be customized Dimension and Tolerance: · Diameter as small as 0.2mm， depends on length · Diameter tolerance we could make as fine as 0.001mm As for the price, please provide the detailed requirements of the ceramic rod to us, such as: size, region, quantity, whether to customize and so on.If you provide detailed information, we will check all the costs and the delivery time is faster. Custom service: We are a professional manufacturer of ceramic rods, selling hot sizes of ceramic rods in stock, also support to customize different specifications of ceramic rods, according to the parameters or drawings provided by the customer. Quick Free Quote . Our official E mail: admin@cerampart.com (Mr admin) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Specification:
1. Refractory, High Temperature Resistance, Maximum Used Temperature: 1800 ºC (3272ºF)...
2. Hardness Strength, Wear Resistance Up To Mohz 9.0; HRA 80-90...
3. High Voltage, Good Insulation Performance ,Electrical Resistivity Up To 10∧14 Ohm.Cm...
4. High Polished Surface Up To Rz0.8(Ra0.1) ...
5. Superior Mechanical Strength, Max 10 MPa.m1/2 Fracture toughness,
6. Pressure Resistance, Max 2300MPa compressive strength...
7. Anti-High Corrosion Resistance, Such As Acid Alkali Resistance...
8. Long Service Life...
9. Other excellent property
Type of ceramic rod us manufacturer (including but not only belows)
| Shaft plunger | Pump plunger |
| Wear rod | Filling Pump plunger |
| Pins rod | Water Pump plunger |
| Piston rod | Plunger rod |
| Shaft rod | Sleeve and bushing rod |
| Machinable rod | Others |
|
Tip: For different industries, equipment,and environment, ceramic rod have different function, We can machining ceramic rod , such as surface polishing, internal and external pipe wall threads, metal parts bonded, different shapes etc by custom requirement. |
|
| Properties | Unit | Alumina (AL2O3) | Zirconia(ZrO2) | ||||
| AL2O3≥95 | AL2O3≥99 | AL2O3≥99.5 | AL2O3≥99.8 | ZTA | YTZ | ||
| Volumetric density | g/cm3 | 3.7 | 3.80-3.85 | 3.85 | 3.9 | 3.8-4.6 | 6 |
| Hardness | HRA≥ | 86 | 88 | 88 | 88 | 86-88 | 88-90 |
| Flexural Strength | Mpa≥ | 300 | 350 | 400 | 400 | 172-450 | 900 |
| Maximum temperature | ℃ | 1500 | 1500 | 1500 | 1500 | 1400-1500 | 1500 |
| Line expansion coefficient | ×10-6/℃ | 7.5 | 8.2 | 8.2 | 8.2 | ||
| Dielectric constant | εr(20℃,1MHz) | 9 | 9.2 | 9.2 | 9.2 | ||
| Media loss | tanδ×10-4,1MHz | 3 | 2 | 2 | 2 | ||
| Volumetric resistivity | Ω·cm(20℃) | 1013 | 1014 | 1014 | 1014 | 1013 | 1014 |
| Breakdown strength | KV/mm,DC≥ | 20 | 20 | 20 | 20 | ||
| Acidic resistance | mg/cm2≤ | 0.7 | 0.7 | 0.7 | 0.7 | ||
| Alkaline resistance | mg/cm2≤ | 0.2 | 0.1 | 0.1 | 0.1 | ||
| Abrasion resistance | g/cm2≤ | 0.2 | 0.1 | 0.1 | 0.1 | ||
| Compressive strength | Mpa≥ | 2500 | 2500 | 2500 | 2800 | 2300-2900 | 2500 |
| Flexural Strength | Mpa≥ | 200 | 350 | 350 | 350 | ||
| Elastic modulus | Gpa | 300 | 350 | 350 | 350 | ||
| Poisson-Pine ratio | 0.2 | 0.22 | 0.22 | 0.22 | |||
| Thermalcoefficient | W/m·K(20℃) | 20 | 25 | 25 | 25 | ||
| Precision of manufacture | |
| Dimensional accuracy | Up to 0.001mm |
| Smoothness | Highest possible mirror |
| Concentricity | Up to 0.003mm |
| Parallelism | Up to 0.002mm |
| The inner hole tolerance | The minimum 0.005mm |
| Straight flute | The narrowest 0.1x100mm |
| The thickness of the size | Minimum to 0.02mm |
| The screw thread | Minimum internal thread M2 |
| Cylindricity | Up to 0.004mm |
| The linear tolerance | Up to 0.001mm |
| The smallest aperture | The minimum 0.07mm |
| Precision process | CNC maching,grinding,lapping |
| Surface finish | Glazed,polishing or metallized |
|
Visual quality: 1. No cracks, no dark dots, no contamination and sharp edges; 2. Evenly distributed glaze with very smooth surface |
|
Customization & Machining Service
As a professional manufacturer of industrial ceramic components.We can custom the sepcial specifications of ceramic rod,tube,bar or other ceramic parts.High quality,Factory price, on-time delivery, High composition of ceramics
FAQ
1. Monthly Capacity: 50,000-60,000 pcs;
2. Material: OEM or as per your suggestion;
3. Lead time: about 7-10 days, pls confirm the quantities required;
4. Incoterm: FOB, CFR, CIF;
5. Delivery Cost: It is determinated by the destination port;
6. Payment Term: PayPal; T/T; L/C.
7. Shipment: by sea, by air, by courier, by post, etc.
Feedback
1. For any query or doubt, please contact us firstly, we will update with you soon;
2. For any other satisfaction, please also feedback to us, which could improve our service better and better.
| For more information about ceramics rods,please contact our engineers in time >>> |
  |
