| · Flexural strength | · Chemical resistance | · Electrical insulation | · Corrosion resistance | · Dielectric strength |
| · Wear resistance | · Temperature resistance | · Thermal conductivity | · High voltage | · Hardness... |
| Tube series | Round Double Bore | Round Four Bore | Oval Double Bore | ||||
| OD | ID | OD | ID | OD | ID | OD | ID |
| 0.050" | 0.020" | 0.063" | 0.016" | 0.063" | 0.016" | 0.077"/0.051" | 0.014" |
| 0.063" | 0.031" | 0.094" | 0.025" | 0.094" | 0.020" | 0.120"/0.070" | 0.031" |
| 0.094" | 0.040" | 0.109" | 0.031" | 0.109" | 0.020" | 0.163"/0.112" | 0.040" |
| Length Range | Length Range | Outside Diameter | Outside Diameter | Inside Diameter | Inside Diameter |
| 4.000-6.875 in | 102-174 mm | 0.031 in | 0.79 mm | 0.005 in | 0.13 mm |
| 6.876-12.875 in | 175-327 mm | 0.031 in | 0.79 mm | 0.005 in | 0.13 mm |
| 12.876-18.875in | 328-479 mm | 0.031 in | 0.79 mm | 0.005 in | 0.13 mm |
| 4.000-6.875 in | 102-174 mm | 0.047 in | 1.19 mm | 0.01 in | 0.25 mm |
| 6.876-12.875 in | 175-327 mm | 0.047 in | 1.19 mm | 0.01 in | 0.25 mm |
| 12.876-18.875in | 328-479 mm | 0.047 in | 1.19 mm | 0.01 in | 0.25 mm |
| 4.000-6.875 in | 102-174 mm | 0.062 in | 1.57 mm | 0.016 in | 0.41 mm |
| 6.876-12.875 in | 175-327 mm | 0.062 in | 1.57 mm | 0.016 in | 0.41 mm |
| 12.876-18.875in | 328-479 mm | 0.062 in | 1.57 mm | 0.016 in | 0.41 mm |
|
Dimension ·Inside Diameter as small as 0.3 mm ·Longth as long as 400mm, as short as 0.5mm ·Inside Diameter tolerance we could make as fine as 0.002mm ·Outside Diameter tolerance as fine as 0.001mm |
Additional Information
·Discounts on large quantities of Ceramic tube ·In stock items will typically ship in a few working days. ·Unit price and estimated ship dates will be calculated when the length and quantity are specified. ·The length and special sizes can be customized |
|
|
Al 2O 3 |
ZrO2/Y2O3 | ZrO2/MgO | MgO | SiC | Si3N4 Reaction sintered | Si3N4 Hot pressed | ALN |
| Physical properties | ||||||||
| Density (g/cm3) | 3,9 | 5,9 | 5,75 | 3,58 | 3,2 | 3,27 | 3,29 | 3,26 |
| Molecular weight (g/mole) | 102 | - | - | 40,4 | 40,1 | 140 | 140 | 41 |
| Maximum service temperature air (°C) | 1700- 1800 | 1500 | 1000 | 2200 | 1500 | 1200- 1500 | 1100- 1600 | 1000- 1800 |
| Mechanical properties | ||||||||
| Hardness (Mohs) | 9 | - | - | 5,5 | 9 | - | - | 7 |
| Modulus of elasticity (GPa) | 300-400 | 200 | 200 | 250-300 | 420 | 170-220 | 280-310 | 318 |
| Poisson's ratio | 0,25 | - | - | 0,18 | 0,14 | 0,25-0,26 | 0,27 | 0,25 |
| Fracture toughness (MPa.m1/2) | 2-3 | 7-13 | 6-10 | - | 2,5-3,5 | 3,5-5 | 6,1 | 4,5 |
| Electrical properties | ||||||||
| Dielectric constant | 9-10 | - | - | 9-10 | - | 10 | 10 | 9,2 |
| Electrical resistivity at 20°C (Ohm.cm) | >10 14 | 10 13-10 14 | >10 10 | - | 10 2-10 6 | >10 7 | 10 12- 10 15 | >10 14 |
| Dielectric strength (kV/mm) | 10-20 | 9 | 2-10 | - | - | - | - | 15 |
| Thermal properties | ||||||||
| Specific heat (J/K/kg) | 900 | 400-500 | 420 | 870-880 | 750 | 690 | 680-800 | 800 |
| Thermal conductivity (W/m/K) at 20°C | 26-35 | 2,2-3,2 | 1,5-2,5 | 40-50 | 63-155 | 9-30 | 15-43 | 180 |
| Coefficient of thermal expansion ( 10-6) from 20 to 1000°C | 8-9 | 10-11 | 5-16 | 10-13 | 4-5 | 3 | 3,3 | 4,4-5,3 |
| Melting point (°C) | 2050 | 2590 | - | 2800 | 2500 | 1900 | 1900 | 2200 |
| Precision of manufacture | |
| Dimensional accuracy | Up to 0.001mm |
| Smoothness | Highest possible mirror |
| Concentricity | Up to 0.003mm |
| Parallelism | Up to 0.002mm |
| The inner hole tolerance | The minimum 0.005mm |
| Straight flute | The narrowest 0.1x100mm |
| The thickness of the size | Minimum to 0.02mm |
| The screw thread | Minimum internal thread M2 |
| Cylindricity | Up to 0.004mm |
| The linear tolerance | Up to 0.001mm |
| The smallest aperture | The minimum 0.07mm |
| Precision process | CNC maching,grinding,lapping |
| Surface finish | Glazed,polishing or metallized |
|
Visual quality: 1. No cracks, no dark dots, no contamination and sharp edges; 2. Evenly distributed glaze with very smooth surface |
|
Customization & Machining Service
As a professional manufacturer of industrial ceramic components.We can custom the sepcial specifications of ceramic tubes, rod or other ceramic parts.High quality,Factory price, on-time delivery, High composition of ceramics
FAQ
1. Monthly Capacity: 50,000-60,000 pcs;
2. Material: OEM or as per your suggestion;
3. Lead time: about 7-10 days, pls confirm the quantities required;
4. Incoterm: FOB, CFR, CIF;
5. Delivery Cost: It is determinated by the destination port;
6. Payment Term: PayPal; T/T; L/C.
7. Shipment: by sea, by air, by courier, by post, etc.
