As a Professional Advanced Technology Ceramic Manufacturers,
Us Support To Customize Different Specifications Of Ceramic Components
|
Dimension and tolerance: ·Diameter as small as 0.2mm， depends on length ·Length as long as 400mm, as short as 0.5mm ·Diameter tolerance we could make as fine as 0.001mm Customization: |
Additional Information:
·Discounts on large quantities of Ceramic Rod ·In stock items will typically ship in a few working days. ·Unit price and estimated ship dates will be calculated when the length and quantity are specified. ·The length and special sizes can be customized |
Advantage Of 95% 97% 99% Alumina Ceramic Stick:
1. High purity, 99.7% alumina purity make sure high working temperature.
2. Tight tolerance, we can grind OD to make tight tolerance for easy insulation.
3. Fast delivery, we have large quantity tubes in stock.
4. Inspection: each single rods will be checked before shipping.
5. Low transportation cost. We have long time cooperated shipping agency, which can provide very low prices.
High heat and temperature:
The ceramic have a excellent high heat temperature resistant ability. Ceramic can be used under 2200 ℃ high temperature environment.up to 10∧13 Coefficient of thermal expansion ( 10∧6) from 20 - 1000°C. up to 2800°C Melting point.
Wear Hardness abrasion:
The ceramic is better wear and abrasion resistant property than metal. The ceramic hardness (mohs)up to 9, HRA 80-90. Ceramic hardness is not second only to diamond, but far beyond the wear resistance of steel and stainless steel
Application Of 95% 97% 99% Alumina Ceramic Ceramic Stick:
1. mining industry
2. Cement industry
3. Coal handling industry
4. Steel industry
5. Port industry
6. Power plant
| · Flexural strength | · Chemical resistance | · Electrical insulation | · Corrosion resistance | · Dielectric strength |
| · Wear resistance | · Temperature resistance | · Thermal conductivity | · High voltage | · Hardness... |
| Properties | Units | AL2O3 | ZrO2 | SiC | Si3N4 |
| Density | g/cm3 | 3.65-3.93 | 5.95-6.0 | 3.12 | 3.23 |
| Water absorption | 0 | 0 | 0 | 0 | 0 |
| Coefficientof thermal expansion | 10-16/k | 7.9-8.5 | 10.5 | 3 | 3.2 |
| Modulus of elasticity young`s mod | GPa | 280-340 | 210 | 440 | 300 |
| Poission`s ratio | / | 0.21-0.22 | 0.3 | 0.17 | 0.26 |
| HV hardness hv | MPa | 1650 | 1300-1365 | 2800 | 1500 |
| Flexural strength | MPa | 310 | 950 | 390 | 720 |
| Flexural strength(700℃) | MPa | 230 | 210 | 380 | 450 |
| Compressive strength | MPa | 2200 | 2000 | 1800 | 2300 |
| Fracture toughness | MPa*m1/2 | 4.2 | 10 | 3.9 | 6.2 |
| Heat conductivity | W/m*k | 26-30 | 2-2.2 | 120 | 25 |
| Electrical resistivity | Ω*mm2/m | >1016 | >1015 | >103 | >1013 |
| Max use temperature | ℃ | 1750 | 1050 | 1550 | 1050 |
| Resistance to acid alkaline | / | high | high | high | high |
| Dielectric constant | / | 9.6 | 29 | 9.66-10.03 | / |
| Dielectric strength | KV/mm | 8.7 | 9 | / | / |
| Thermal shock resistance | △T（℃） | 180-220 | 280-350 | 230-260 | / |
| Tensile strength | MPa | 248 | 250 | / | / |
| Precision of manufacture | |
| Dimensional accuracy | Up to 0.001mm |
| Smoothness | Highest possible mirror |
| Concentricity | Up to 0.003mm |
| Parallelism | Up to 0.002mm |
| The inner hole tolerance | The minimum 0.005mm |
| Straight flute | The narrowest 0.1x100mm |
| The thickness of the size | Minimum to 0.02mm |
| The screw thread | Minimum internal thread M2 |
| Cylindricity | Up to 0.004mm |
| The linear tolerance | Up to 0.001mm |
| The smallest aperture | The minimum 0.07mm |
| Precision process | CNC maching,grinding,lapping |
| Surface finish | Glazed,polishing or metallized |
|
Visual quality: 1. No cracks, no dark dots, no contamination and sharp edges; 2. Evenly distributed glaze with very smooth surface |
|
Customization & Machining Service
As a professional manufacturer of industrial ceramic components.We can custom the sepcial specifications of ceramic plates,blocks or other ceramic parts.High quality,Factory price, on-time delivery, High composition of ceramics
FAQ
1. Monthly Capacity: 50,000-60,000 pcs;
2. Material: OEM or as per your suggestion;
3. Lead time: about 7-10 days, pls confirm the quantities required;
4. Incoterm: FOB, CFR, CIF;
5. Delivery Cost: It is determinated by the destination port;
6. Payment Term: PayPal; T/T; L/C.
7. Shipment: by sea, by air, by courier, by post, etc.
Feedback
1. For any query or doubt, please contact us firstly, we will update with you soon;
2. For any other satisfaction, please also feedback to us, which could improve our service better and better.
| For more information about ceramics parts,please contact our engineers in time >>> |
  |
