Ceramic rod stock

Location：Home > Ceramic OEM > Ceramic rod stock >

High performance ceramic rods - ceramic manufacturer

Multi types and sizes - in stock and custom - factory price

We manufacture and sell high-quality, high-precision ceramic rods. Our ceramic rods are multi-size, multi-type and have a wide range of applications.
MOQ: 1 qty
Delivery time: within 2 days for in stocks
Payment Term: PayPal; T/T; L/C; etc.
Shipment: by sea, by air, by courier, by post, etc.
Price: depend on the quantity and sizes(Factory price)
Dimensions:0.393” to 21.654” (10mm – 550mm) length;Diameter as small as 0.2mm(can be customizations)

Please contact us : admin@cerampart.com

Ceramic components:
1. Alumina ceramic(Al2O3):
95%;96%;97%;98%;99%;99.5%:99.7%;99.9%
2. Zirconia ceramic(Zro2):
TTZ: Magnesia Partially Stabilized Zirconia (Zro2)
YTZP: Yttria Partially Stabilized Zirconia (Zro2)
ZDY: Yttria Fully Stabilized Zirconia (Zro2)
3. Silicon Carbide
4. Silicon Nitride
5. And others

The type of ceramic rod
Cylindrical, Square, Screw Threadand, Porous...

Shaft,Plunger Rod,Piston Rod,Cylinder Rod,Insulating Rod,Heat Conducting Bar,sharpening rod,honing rod...

Specification:
1. Refractory, High Temperature Resistance, Maximum Used Temperature: 1800 ºC (3272ºF)...
2. Hardness Strength, Wear Resistance Up To Mohz 9.0 Levels...
3. High Voltage, Good Insulation Performance ,Electrical Resistivity Up To 10∧14 Ohm.Cm...
4. High Polished Surface Up To Rz0.8(Ra0.1) ...
5. Superior Mechanical Strength, Max 10 MPa.m1/2 Fracture toughness,
6. Pressure Resistance, Max 2300MPa compressive strength...
7. Anti-High Corrosion Resistance, Such As Acid Alkali Resistance...
8. Long Service Life...
9. Other excellent property

The best-selling sizes are as follows in stock:

OuterDiameter (Inch)	Outer Diameter (mm)	Maximum Length(Inch)/(mm)		Price	Ask for other sizes
0.011	0.28	3.94	100	Get the latest price	contact us :admin@cerampart.com
0.020	0.51	3.15	80	Get the latest price	contact us :admin@cerampart.com
0.022	0.56	6.69	170	Get the latest price	contact us :admin@cerampart.com
0.024	0.61	5.12	130	Get the latest price	contact us :admin@cerampart.com
0.029	0.74	5.91	150	Get the latest price	contact us :admin@cerampart.com
0.030	0.76	1.97	50	Get the latest price	contact us :admin@cerampart.com
0.035	0.89	2.76	70	Get the latest price	contact us :admin@cerampart.com
0.040	1.02	7.48	190	Get the latest price	contact us :admin@cerampart.com
0.041	1.04	6.30	160	Get the latest price	contact us :admin@cerampart.com

Ceramic Materials Ceramic Property Produce and Customization Shipment and Service

Ceramic materials(include but not limited belows)
· 95%--99.99% Alumina (Al2O3) · Silicon Carbide · Silicon Nitride · TTZ: Magnesia partially stabilized Zirconia (ZrO2)
· YTZP: Yttria partially stabilized Zirconia (ZrO2) · ZDY: Yttria fully stabilized Zirconia (ZrO2)...

	Al ₂O ₃	ZrO2/Y2O3	ZrO2/MgO	MgO	SiC	Si3N4 Reaction sintered	Si3N4 Hot pressed	ALN
Physical properties
Density (g/cm3)	3,9	5,9	5,75	3,58	3,2	3,27	3,29	3,26
Molecular weight (g/mole)	102	-	-	40,4	40,1	140	140	41
Maximum service temperature air (°C)	1700- 1800	1500	1000	2200	1500	1200- 1500	1100- 1600	1000- 1800
Mechanical properties
Hardness (Mohs)	9	-	-	5,5	9	-	-	7
Modulus of elasticity (GPa)	300-400	200	200	250-300	420	170-220	280-310	318
Poisson's ratio	0,25	-	-	0,18	0,14	0,25-0,26	0,27	0,25
Fracture toughness (MPa.m1/2)	2-3	7-13	6-10	-	2,5-3,5	3,5-5	6,1	4,5
Electrical properties
Dielectric constant	9-10	-	-	9-10	-	10	10	9,2
Electrical resistivity at 20°C (Ohm.cm)	>10 ₁₄	10 ₁₃-10 ₁₄	>10 ₁₀	-	10 ₂-10 ₆	>10 ₇	10 ₁₂- 10 ₁₅	>10 ₁₄
Dielectric strength (kV/mm)	10-20	9	2-10	-	-	-	-	15
Thermal properties
Specific heat (J/K/kg)	900	400-500	420	870-880	750	690	680-800	800
Thermal conductivity (W/m/K) at 20°C	26-35	2,2-3,2	1,5-2,5	40-50	63-155	9-30	15-43	180
Coefficient of thermal expansion ( 10-6) from 20 to 1000°C	8-9	10-11	5-16	10-13	4-5	3	3,3	4,4-5,3
Melting point (°C)	2050	2590	-	2800	2500	1900	1900	2200

Ceramics are oxides, carbides, nitrides and borons of metal ions. Generally speaking, they are inorganic and non-metallic. Ceramics play an important role in our daily life. The development of ceramics has helped to reduce industrial demand. Compared with other materials, ceramics have some unique properties.

Physical Properties: ·Volume ·Density ·Melting point ·Boiling point ·Heat capacity ·Index of reflection ·Porosity (also we refer pore size)	Mechanical Properties: ·compressive strength ·shear strength ·fracture toughness ·elasticity or plasticity ·ductility ·Hardness	Electrical Properties: ·dielectric strength ·electrical conductivity ·insulating properties ·semiconducting properties ·superconducting properties ·dielectric constant
Thermal Properties: ·insulating properties ·semi-conducting properties ·thermal conductivity ·thermal expansion ·thermal shock resistance	Chemical Properties: ·alkali attack resistance ·acid attack resistance ·corrosion resistances	Other ceramic properties...

Know more details of the ceramics property, contact us ： admin@cerampart.com

Customization & Machining Service:
As a ceramic parts manufacturer,us offer a wide of the ceramic specification,and customized&machinables. Get a Quote On Your Customized Now!! or up a files by (email:admin@cerampart.com).

Our Custom Capabilities:
1.High Purity Martoxid Powder
2.OEM Support, More Than 10 Technicians With 5-Year R&D Experience
3.35000 ㎡workshop, annual output could reach hundred million pieces.
4.All crafts are inspected strictly based on drawings,checked each month.
5.Best Service And Quick Delivery Via Fedex,DHL,UPS,TNT Etc.

Technical reference of manufacture
Dimensional accuracy	Up to 0.001mm
Concentricity	Up to 0.003mm
Parallelism	Up to 0.002mm
The inner hole tolerance	The minimum 0.005mm
Straight flute	The narrowest 0.1x100mm
The thickness of the size	Minimum to 0.02mm
The screw thread	Minimum internal thread M2
Cylindricity	Up to 0.004mm
The linear tolerance	Up to 0.001mm
The smallest aperture	The minimum 0.07mm
Precision process	CNC maching,grinding,lapping
Surface finish	Glazed,polishing or metallized

The general specifications service
1. Factory price with a discounts
2. Fast shipment within 24 hours
3. In stocks for hot sales sizes
4. MOQ:1qty

The Custom service
1. Can be custom for special sizes by drawing
2. Can offer a samples within 2 days
3. The delivery time within 20 days after confirmed the order
4. Factory price and Senior ceramic engineer service

FAQ
1. Monthly Capacity: 50,000-60,000 pcs;
2. Material: OEM or as per your suggestion;
3. Lead time: about 7-20 days, pls confirm the quantities required;
4. Incoterm: FOB, CFR, CIF;etc
5. Delivery Cost: It is determinated by the destination port;
6. Payment Term: PayPal; T/T; L/C; etc.
7. Shipment: by sea, by air, by courier, by post, etc.
